XTOOL D8 Functions
Automotive professional diagnostic tools ECU coding , Matching , Actuation test, Full System Scanner with 5.1Android Systems TouchScreen , 2GB RAM + 64GBROM，3 Years Free Update , 5 Years Warranty
OE-Level Full System Diagnostics: XTOOL D9 is an OE-level full diagnostic scanner as it can scan ECUs in different types of vehicle systems and subsystems such as engine, TCM(Transmission), SRS(Airbag), ABS, TPMS, BCM, BODY, AC and much more, read /clear codes, view the live data from each available system, perform active tests to check the work status of modules, providing you with a Dealership- Level only diagnosis, getting the accurate and in-depth results across all automotive systems.
Smart AutoVin & Auto Scan+BT Connection+Cable Connection：XTOOL D9 provides you with more efficient diagnosis work. You just need to plug the VCI into the OBD2 port, within a working range of 33 feet(10 m), you can use the D9 to communicate with the vehicle through BT connection, providing you with higher mobility. Use AutoVin to automatically read the vehicle identification number, or access the OBDII menu to use Auto Scan to perform a comprehensive scan of all available modules to shorten the diagnosis time.
Commonly-Used 30+ Services: XTOOL D9 With car service tool is designed for mechanics and workshop, garages. Along with the standard service functions like Oil Reset, EPB, SAS Adjustment, DPF Regeneration, Throttle Relearn and Injector Coding, IMMO, ABS Bleeding, TPMS Reset, BMS Reset, etc. Note: Service functions does not work on all vehicles.
Bi-Directional Control/Active Tests+ECU Coding ：XTOOL D9 is a bi-directional scan tool with ECU codding ,allows you to receive information to and from the vehicle’s onboard computer and can send commands to the vehicle ECU to perform active tests without using the vehicle’s controls, like A/C Clutch on/off, Fuel Injectors, (Cycling) ABS Pump Motor, window, door, sunroof, etc. That’s helpful for DIY mechanics, speeding up the troubleshooting process when it’s time to make repairs.
Excellent Tablet Quality+Multi-Language ：10000 Mah 3.7V Battery with 8MP Camera can works with our XV100 Endoscope， 10 inch biggr screen with 2GB RAM + 64GBROM Memory space，with bluetooth and wifi few keep update online +12 kinds of language
85+ Brands, 10000+ Cars Coverage & 14 Languages：XTOOL A80 car diagnostic scanner can work on more than 85+ US domestic, European, and Asian makes and models, more than 10000 cars, the extensive vehicle coverage can provide you with almost every diagnostic option a mechanic could need. With a multilingual menu, you can easily switch between languages, allowing mechanics to avoid language barriers and focus on their vehicle data.
Support Newest Doip and with CAN FD Functions the D9 can works for the Doip protocol and CAN FD .CAN-FD data frame newly adds EDL bit, BRS bit, ESI bit in the control field, and adopts new DLC encoding method and new CRC algorithm (CRC field is extended to 21 bits)
Newest Update of XTOOL D9
2021 ADVANCE FUNCTION: SUPPORT EXTENSION MODULES（need to buy additionally）To XTOOL D9 Better on Key programmer or Diagnostic more Better
1. Videoscope (Mainly applied to check unseen parts of engine, fuel tank, braking system, etc.)
2. KC501 (For Benz infrared key programming,For VW 4th ,,5th immo, For Eeprom ,For Chips programmer)
3.KC100 (For VW 4th and 5th immo )
4.KS01(For toyota all key lost programmer )
5.Ks02( For Mitsubishi all key lost programmer）
Optimized HIGH-END Hardware Configurations:
The screen size of XTOOL D9 (9.7 inches) based on Andoird 9.0 is larger. One screen can display 15 data stream (Graphic and textual), which is easy to navigate.
10000mAh rechargeable battery (up to 20 hours or more of battery life) to avoid frequent charging.
2GB+64GB ROM storage to save more vehicle documents and customer data.
CPU processor updated been 1.8GHz eight-core to perform diagnostics quickly and efficiently.
D9PRO ECU Programmer
ECU PROGRAMMER For Benz/BMW/VW/Ford/Mazda
D9 pro Support the Online ECU Programmer For Benz/BMW and VW and Offline ECU Programmer for Ford /Mazda
Can Programming new ECUs(PCM, ECM)
Special Functions what’s D9 including
Special Functions what’s D9 including
Because every automobile actuator has a record code in ECU, which is the basis for automobile computer to mobilize their work. XTOOL D99 is equipped with advanced ECU coding function for addressing the following issues:
After you change the bad actuators or certain parts, you need to use this function to make a new code and recognize the new actuators.
By changing the code with the ECU coding, it’s easy to improve vehicle performance or stimulate high-end functions for the car.
ECU coding enables multiple car systems to recognize each other and then the actuators can start to work.
ECU Online Coding is available for BMW, VW, Porsche, Renault, etc.
Please Note: ECU Coding changes preprogrammed options which depend on the type and number of electronic features already built in. Thus, ECU coding is not universally compatible and varies for different vehicles.
2.All System Bidirectional Scan Tool -XTOOL D9 (Bigger,Bidirectional,Better )
With this diagnostic tool’s Active Test, you can output the command into the ECU in order to turn on/off actuators, to find faults in the subsystems of your car effortlessly, without using the vehicle’s control: Turn on the radiator fan | Modulate the throttle | Open/close windows | Operate mirrors | Turn on/off the lights | Turn on/off the sound horn | Test door lock … （Available test varies by the vehicle manufacturer, year, and model.）
3.Support DoIP protocol
4.Support CAN FD protocol
6. Auto Vin Scan ：Smart AutoVIN technology for fast and precise identifying vehicles in one touch to scan ECUs, acquire vehicle info and run diagnostic on selected systems.Quickly get your car’s information,save your time.
ECU CODING – The Coding function is used to re-flash the vehicle control modules, it allows you to reprogram adaptive data for certain components after making repairs or replacements.
OIL RESET – Reset the oil life systems every time the oil and oil filter are changed;
INJECTOR CODING– Code new injector numbers to replace the previous one when fitting the new injectors or after the replacement is completed;
BRAKE RESET – Deactivate and activate the brake control system, assist with brake fluid control, open and close brake pads, etc.;
SAS RESET – Perform steering angle sensor calibration and clear records;
BATTERY.RESET – Evaluate the battery charge state, monitor the closed-circuit current, register the battery replacement, etc.;
ABS BLEEDING– When the ABS contains air, the ABS bleeding function must be performed to bleed the brake system to restore ABS brake sensitivity;
ELEC.THROTTLE RLRN – Initialize the throttle actuators so that the “learned” values stored on ECU are returned to the default state;
TPMS RESET – Tire pressure resetting is required to be performed after maintenance is performed;
Key Programmer: Help ECU to recognize the new keys when you need to add new keys.
DPF REG – Clear PM (Particulate Matter) from the DPF filter through continuous combustion oxidation mode to stabilize the filter performance;
GEAR LEARN – Perform gear learning for the car when the engine ECU, the crankshaft position sensor, or the crankshaft flywheel is replaced.
One-Click Generate Health Report: Health Report will scan all vehicle modules and give you a status list for each modules condition. Also known as “Global Test” or “Full Scan” .This diagnostic tool can automatically generate a diagnostic report when diagnostic work is successfully finished.The reports are saved to the internal memory for later review. The reports are able to be saved in PDF format, and as the tablet is equipped with WIFI, these can be emailed to the office or directly to the customer.
Online Repair Resources: Provide more than 200000+ vehicle models’ service & repair information, handbook, repair case and operation skill
One-Click identify VIN: Smart AutoVIN technology for fast and precise identifying vehicles in one touch to scan ECUs, acquire vehicle info and run diagnostic on selected systems.Quickly get your car’s information,save your time.
Maintenance Help: Including How-to Videos, operation skills, and user manual, Q&A, Quick start guide, etc.
Extensive Vehicle Coverage – 200000+ Cars supported:
Aisa: Compatible with (JAPAN) Acura, Daihatsu, Honda, Infiniti, Isuzu, Jpisuzu, Lexus, Mazda, Mitsubishi, Nissan, Nissan GTR, Scion, Subaru, Subaru, Suzuki, Tlisuzu, (KOREA) Daewoo, Hyundai, KIA, Samsung, Ssangyong; (CHINA) Baic, Beijing, Changan, Changan-Ford, Changcheng, Changhe, Chsuzuki, DF Peugeot, DF Honda, DF Nissan, DF XK, Flyer,BYD, Fukang, Futian,Foton, Geely, Gonow, GZ Honda, Hafei, Haoqing, HC BMW, Hmada, Huachen, Isuzu, JMC, Jacty, Jianghuai, Jiao, Jinlong, Joylong, Lifan, Liuwel-TY, Luxgen, NJ Fiat, Qirul-TY,chery, Qoros, Saicmg, Spark-TY, Trumpchi GAC, Weili, Xiaokang Dongfeng, Xili,Faw Tianjin, Xinkai, YQ Mazda, Zhongshun, Zhongtai, Zotye, Zhongxing (MALAYSIA) Perodua, Proton, (IRAN)MVM
Europe: Compatible with Vaz, Porsche, Maserati, BMW, Seat, VW, Audi, Citroen, Landrover, Smart, Renault, Skoda, Sprinter, Land Rover, Benz, Fiat, Opel, Volvo, Peugeot, Ferrari, Saab, Gaz, DR
USA: Compatible with Gm, USAFord, Chrysler, Willy; Australia: Compatible with Austford, Holden; Brazil: Compatible with BXFiat, BXGM
